12G-SDI to Fiber Converter with Gigabit Ethernet and 2Ch Backward RS485

Name: 12G-SDI to Fiber Converter with Gigabit Ethernet and 2Ch Backward RS485
Brand: E-link China Technology Co.,LTD
SKU: LNK-12GSDI-1V2R1GE Series
Price: 594.00 USD
Availability: InStock

Detalles del producto

Place of Origin: China

Nombre de la marca: E-link

Model Number: LNK-12GSDI-1V2R1GE Series

Documento: E-link LNK-12GSDI-1V2R1GE 1....0.pdf

Condiciones de pago y envío

Minimum Order Quantity: 1 pcs

Precio: Negociable

Packaging Details: Carton Packaging

Delivery Time: 3-12 working days

Payment Terms: L/C,T/T,Western Union,MoneyGram,Paypal

Supply Ability: 1000 pcs/month

Obtenga el mejor precio

Contacta ahora

Especificaciones

Descripción

Especificaciones

Resaltar:

Ethernet:	10/100/1000Mbps	Dimensions (LxWxH):	117 x 80 x 24 (mm)
Power:	12 VDC	Power Consumption:	6 W (Max.)
Operating Temperature (℃):	-10℃～70℃	Storage Temperature:	-40℃～85℃

Ethernet:	10/100/1000Mbps
Dimensions (LxWxH):	117 x 80 x 24 (mm)
Power:	12 VDC
Power Consumption:	6 W (Max.)
Operating Temperature (℃):	-10℃～70℃
Storage Temperature:	-40℃～85℃

Descripción

12G-SDI to Fiber Converter with Gigabit Ethernet and 2Ch Backward RS485

Advantages

► Each SDI channel includes 8-channel audio embedded

► Automatic cable equalization to ensure signal integrity

► Supports ST-2082-1(12G), ST-2081-1(6G), ST-424(3G), ST-292(HD) and ST-259(SD)

► Integrated Reclocker Locks to SMPTE Rates of 11.88Gbps, 5.94Gbps, 2.97Gbps, 1.485Gbps or Divide-by-1.001 Subrates and 270 Mbps

► Directly compatible with 12G/6G/3G-SDI camera systems

► Long transmission capability up to 80 km

► Support 2Ch Backwards RS485

► Supports 1Ch 10/100/1000M Ethernet

► Full digital non-compression broadcast level transmission;

► Super optic dynamic range and free of adjustment;

► Fiber optic WDM/CWDM/DWDM technique;

Supports 4K*2K(3840*2160@60Hz),1080P,1080I,720P.

Overview

LNK-12GSDI-1V2R1GE Series 12G-SDI Fiber Converter supports 1Ch 12G Video (audio embedded) &1Ch Gigabit Ethernet&2Ch Backward RS485 transmitted via fiber optical cable, and monitor the signal locally over a 12G loop output. E-link 12G Video over Fiber Converters includes one transmitter and one receiver for HDTV 4K*2K(3840*2160@60Hz), 1080P,1080I, 720P.

Technical Indexes

Formats	Supports ST-2082-1(12G), ST-2081-1(6G), ST-424(3G), ST-292(HD) And ST-259(SD)
Compatible	Compatible With DVB-ASI and AES10 (MADI)
Input	1 x 12G-SDI on BNC
Output	2 x FC optical fiber
Output	1 x 12G-SDI loop-out on BNC
Supported Resolution	HDTV 4K*2K, 1080P, 1080I, 720P
Resolution range	3840*2160@60Hz
Input cable specification	≤70m@12G SDI Belden 1694A
Output cable specification	≤60m@12G SDI Belden 1694A
Ethernet	10/100/1000Mbps
Data type	2Ch Backward RS485
Optical transmission bandwidth	270MHz～12GHz
Power	12 VDC
Power Consumption	6 W (Max.)
Dimensions (LxWxH)	117 x 80 x 24 (mm)
Operating Temperature	-10℃～70℃
Storage Temperature	-40℃～85℃

Application

12G-SDI to Fiber Converter with Gigabit Ethernet and 2Ch Backward RS485 1
